Columnas acústicas

C-660A

Acoustic column 12 x 2,5'', 60 W RMS (60 y 30 W), 100 V

Columna acústica de 60 W de potencia de la serie C-600A. Fabricada en aluminio color blanco, permitiendo su instalación tanto en interiores como en exteriores. 12 altavoces de 2,5" para aumentar la direccionalidad del conjunto. Selector de potencia de 30 W y 60 W. Respuesta en frecuencia de 170 Hz a 15.000 Hz. Sensibilidad de 93 dB (1 W, 1 m). SPL máximo 111 dB. Dimensiones 106 x 985 x 75 mm. Peso 5,20 Kg. Incluye soporte metálico orientable. Modelo OPTIMUS ref. C-660A.

datasheet

C-640A

Acoustic column 8 x 2,5'', 40 W RMS (40 y 20 W), 100 V

Acoustic column with power rating of 40 W (selectable to 20 W) in 100 V line. 8 x 2.5" speaker. Frequency response of 170-15.000 Hz. Sensitivity 93 dB (1 W, 1 m and 1 kHz). Maximum sound pressure level 109 dB (40 W, 1 m and 1 kHz). Weight 3.46 kg. Dimensions 106 x 691 x 75 mm. Finishing in white aluminium, with swivel bracket for wall mounting. Suitable for outdoor and indoor use. OPTIMUS model ref. C-640A.

datasheet

C-630A

Acoustic column 6 x 2,5'', 30 W RMS (30 & 15 W), 100 V

Acoustic column with power rating of 30 W (selectable to 15 W) in 100 V line. 6 x 2.5" speaker. Frequency response of 170-15.000 Hz. Sensitivity 92 dB (1 W, 1 m and 1 kHz). Maximum sound pressure level 107 dB (30 W, 1 m and 1 kHz). Weight 2.74 kg. Dimensions 106 x 548 x 75 mm. Finishing in white aluminium, with swivel bracket for wall mounting. Suitable for outdoor and indoor use. OPTIMUS model ref. C-630A.

datasheet

C-620A

Acoustic column 4 x 2,5'', 20 W RMS (20 & 10 W), 100 V

Acoustic column with power rating of 20 W (selectable to 10 W) in 100 V line. 4 x 2.5" speaker. Frequency response of 170-15.000 Hz. Sensitivity 91 dB (1 W, 1 m and 1 kHz). Maximum sound pressure level 104 dB (20 W, 1 m and 1 kHz). Weight 2.04 kg. Dimensions 106 x 405 x 75 mm. Finishing in white aluminium, with swivel bracket for wall mounting. Suitable for outdoor and indoor use. OPTIMUS model ref. C-620A.

datasheet

C-1480

Acoustic column 4 x 5", 80 W RMS (80, 60 & 40 W), 100 V. Indoor & outdoor use

Acoustic column with power rating of 80 W (selectable to 60 and 40 W) in 100 V line. 4 x 5" bicone speaker. Frequency response of 100-17.000 Hz. Sensitivity 96 dB (1 W, 1 m and 1 kHz). Maximum sound pressure level 115 dB (80 W, 1 m and 1 kHz). Weight 5.7 kg. Dimensions 197 x 905 x 118 mm. OPTIMUS model ref. C-1480.

datasheet

C-1360

Acoustic column 3 x 5", 60 W RMS (60, 45 & 30 W), 100 V. Indoor & outdoor use

Acoustic column with power rating of 60 W (selectable to 45 and 30 W) in 100 V line. 3 x 5" bicone speaker. Frequency response of 100-17.000 Hz. Sensitivity 95 dB (1 W, 1 m and 1 kHz). Maximum sound pressure level 112 dB (60 W, 1 m and 1 kHz). Weight 4.4 kg. Dimensions 197 x 700 x 118 mm. OPTIMUS model ref. C-1360.

datasheet
