OPTIMUS S.A. is the leading Spanish company in the design, manufacture and distribution of public address (PA), voice alarm (VA) and intercom equipment.


PM-61M

PM61MMixer preamplifier with 6 inputs and sound source FM/MP3

The new model PM-61M of OPTIMUS is a simple but versatile preamplifier, offering a multi-functional solution for installations where multiple voice and music sources need to be mixed to one output zones. The design with six balanced inputs allows connecting any type of audio source. The first two channels are for microphone and line level audio sources, with 3-band tone control, phantom power and talk over for priority announcements. Four more channels are prepared to connect line level audio sources. On the front panel there is the output master volume control, 2-band tone control, the output level meter and the input volume control for each channel. On the back of the preamplifier is a priority mute contact that suppresses all non-priority audio signals in case of contact closure, allowing linking autonomous alarm systems. The built-in music source has an FM radio tuner and MP3 file player from USB memory or SD memory cards.

datasheet

PM-4P

PM4PMixer preamplifier module with balanced inputs (2 mic & 2 stereo aux). Wall mount

Mixer Preamplifier for wall mounting with 2 balanced microphone signal inputs and 2 aux signal inputs. Microphone inputs with phantom power selection. Balanced output of 0 dB, 600 ohms. Power supply 230 V AC, 24 V DC or Phantom. Dimensions 223 x 167 x 59 mm. OPTIMUS model ref. PM-4P.

datasheet

PM-4E

PM4EMixer preamplifier module with balanced inputs (2 mic & 2 stereo aux). Flush mount

Mixer Preamplifier for flush mounting with 2 balanced microphone signal inputs and 2 aux signal inputs. Microphone inputs with phantom power selection. Balanced output of 0 dB, 600 ohms. Power supply 230 V AC, 24 V DC or Phantom. Dimensions 220 x 164 x 9 mm. OPTIMUS model ref. PM-4E.

datasheet
